Composite Rocket & Missile Tube Machines

Custom built traveling column style machine tools designed to machine rocket and missile composite launch tubes. Custom workholding systems, integral milling and grinding spindles all working together to provide unsurpassed productivity. Traveling column design features flexibility for single or multiple part set-up. Built in USA using only high-quality components for excellent reliability.

Composite Rocket & Missile Tube Machines

Traveling column machine design
Rotating part fixture allows speeds of over 500 RPM
Built in grinding spindles
Horizontal and vertical milling spindles
Large work area for multiple part set-ups

REQUEST INFO

OVERVIEW

Overview

Custom made and USA built Missile and Rocket launch tube manufacturing machines. Multiple machining operations done in one set-up. Automated material handling allows lights out manufacturing. Traveling column design features flexibility for single or multiple part set-up. Built in USA using only high-quality components for excellent reliability.

Features

Dual traveling columns
High speed rotary table with matching end support
Vertical and horizontal spindles
Multiple grinding stations with fully programable motion control
Multi channel CNC control

Productivity

Integrated material handling system
Automated measuring system
Lights out machining
Integrated workholding system
USA based service and support team

CNC Control

Overview

The Fryer / Siemens 828-HS control is designed for ease of use in low volume toolroom and job shop facilities. Simple menu programming and fast set-up keys allow you make one-off parts in half the time of a manual machine. Multi mode operation allows you to use the machine manually, semi-automatic and full CNC mode. Canned cycles and graphic verify make set-up faster and easier.

FRYER-SIEMENS 828-HS CNC

Manual or CNC
Do-one mode
Teach mode
Conversational mode

TECHNOLOGY

Ultra reliable Siemens High Speed all digital control system
Regenerative drives save 40% electrical use
Digital drives provide better accuracy and surface finish
Absolute encoders never require you to ‘home’ machine

Geometry Creator
Enter part dimensions using the Simple Geometry Creator. The dimensions are drawn on the screen while you enter them and missing information is automatically calculated.

Pocketing Cycles
Choose from a wide variety of pocket shapes. Then answer basic questions about the depth of cut, tool type and finish stock allowance.

Drilling Cycles
Choose from a wide variety of drill cycles including drill, deep hole drill, peck drill, bore, rigid tap, rigid peck tap and more.

3D Graphic Simulation
The 828-HS uses sophisticated solid model graphic verification to accurately show what your part will look like BEFORE you cut it. Also choose from wireframe or multiview screen.
